CMM Holding Fixtures

Price 5000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

CMM Holding Fixtures Specification

Life Span
Up to 10 Years (Depending on Use)

Working Process
Precision Workpiece Holding during CMM Inspection

Shaping Mode
Modular Adjustable Clamping

Material
Aluminum, Stainless Steel & Polycarbonate

Application
Coordinate Measuring Machine (CMM), Quality Control, Metrology Labs

Hardness
Varies by Component; typically 60-65 HRC (Steel Parts)

Tolerance
0.01 mm

Fixture Type
CMM Holding Fixture Modular System

Packaging
Foam-lined Hard Case or Wooden Box

Corrosion Resistance
High

Clamping Method
Quick Release Dovetail, Magnetic, or Screw Clamp

Compatibility
Suitable with Various CMM Models (Bridge, Cantilever, Gantry Types)

Color
Silver / Black

Base Plate Size
Standard: 300 x 300 mm (Custom Sizes Available)

Finish
Anodized / Powder Coated / Nickel Plated

Weight Capacity
Up to 50 kg (Depending on Model and Configuration)

Operating Temperature Range
0C to 60C

CMM Holding Fixtures Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

CMM Holding Fixtures About

Select a decorated CMM Holding Fixture Modular System renowned for its venerable engineering and astonishing precision. Procure fixtures with anodized, powder coated, or nickel plated finishes, tailored to different inspection demands. The standard 300 x 300 mm base plate and custom sizes are available, while instant savings come from quick release dovetail, magnetic, or screw clamp methods. Designed for compatibility with various CMM models, these fixtures promise high corrosion resistance, a 50 kg weight capacity, and an impressive lifespan up to 10 years-making them indispensable in metrology labs and quality control settings across India.

Comprehensive Application of CMM Holding Fixtures

CMM Holding Fixtures are expertly used as precision workpiece holders during CMM inspection, ensuring absolute stability for accurate measurement. Their modular, adjustable clamping systems accommodate diverse workpieces, making them vital in metrology labs, quality control departments, and manufacturing sites. Typical areas of application include coordinate measuring machines used for advanced dimensional analysis, ensuring each component measured meets stringent industry standards. These fixtures are essential wherever precise measurement and reliable sample positioning are required.

Robust Supply, Packaging Options, and Timely Delivery

We supply reliable CMM Holding Fixtures throughout the domestic market, with the proposal amount tailored to project specifics. Each fixture is carefully packaged in a foam-lined hard case or sturdy wooden box to guarantee protection during transit. With substantial supply capabilities, we can meet diverse procurement needs efficiently. Delivery times are streamlined, ensuring timely arrival-most orders are fulfilled within a stipulated timeframe to keep your quality control processes running uninterrupted.

FAQ's of CMM Holding Fixtures:

Q: How do CMM Holding Fixtures ensure precise workpiece positioning during inspection?

A: These fixtures utilize modular adjustable clamping systems-such as quick release dovetail, magnetic, or screw clamp methods-to securely hold varying shapes and sizes of components for accurate, repeatable measurement during CMM inspection.

Q: What is the benefit of selecting a CMM Holding Fixture with high corrosion resistance?

A: Opting for a fixture with anodized, powder coated, or nickel plated finishes delivers high corrosion resistance, extending the fixture's life span and ensuring durability even under frequent use in demanding environments.

Q: Where are CMM Holding Fixtures commonly used?

A: They are extensively used in metrology laboratories, quality control departments, manufacturing plants, and areas where coordinate measuring machines perform dimensional analysis and precision testing.

Q: What is the supply ability and typical delivery time for CMM Holding Fixtures?

A: We can efficiently supply CMM Holding Fixtures across the domestic market, with most orders dispatched in a timely manner. Standard delivery is carried out according to the project's proposal amount and requirements, generally within the agreed timeframe.

Q: When should I consider ordering custom base plate sizes for my fixture?

A: Custom sizes are advisable when your workpieces exceed the standard 300 x 300 mm base plate or when unique measurement setups require specialized clamping configurations for optimal accuracy.

Q: What is the process to maintain and maximize the lifespan of a CMM Holding Fixture?

A: Regular cleaning, appropriate storage in a foam-lined case or wooden box, and adherence to the recommended weight and temperature limits will help maximize longevity-often up to 10 years depending on use.
